List of SCCM Comanagement Capabilities Values

Moving your devices to the cloud is many organization priorities. Since the release of SCCM 1710, you can decide which feature is managed by SCCM or Intune. This is great as you can now move more workloads allowing a smoother transition to Intune. SCCM Comanagement has evolved a lot since SCCM 1710 and the SCCM Comanagement Capabilities Values have changed values. This post aims to list all possible values on an SCCM 2111+ clients.

But before, let’s list possible Comanagement workloads. If you need more details about the whole comanagement concept, read our post on the topic.

• Compliance Policies
• Resource Access Policies
• Device Configuration
• Windows Update Policies
• Client Apps
• Office Click-2-Run Apps
• Endpoint Protection

Each workload is assigned a specific numerical value, referred as the capability number. This value can be easily viewed in the ConfigMgr control panel applet and the CoManagementHandler.log file.

Now you may wonder why you probably have a numeric value different than that. Keep reading.

SCCM Comanagement Capabilities Values Explained

The reason is that each workload value must be added up to attain their final value. For example, the value 12541 in SCCM co-management state indicates that the device has comanagement enabled and that Intune is managing some workloads while SCCM still manages others.

To get to 12541, you need to take each value of the above table and add their value to 8193 which is the base number :

• 12541 = CoManagement Enabled (8193) +Client_Apps (64) + Device_Configuration (8) + Endpoint_Protection (4128) + Office_Click2Run_Apps (128) + Resource_Access_Policies (4) + Windows_Update_Policies (16)

Here’s the “minimum” and the “maximum” values :

• 8193 would be “no workload has been moved to Intune” (all slider to SCCM)
• 12543 would be “all workloads have been moved to Intune” (all sliders to Pilot Intune or Intune)

To simplify this, we compiled all possible SCCM co-management capabilities values in this table so that you don’t have to do the math for each client:

SCCM Comanagement Report

If you are looking for deeper insights on the co-management information, we have got you covered with our custom SCCM Comanagement Report.

This dashboard can run against a specific collection (filter) and is split into the following sections:

• Client OS Distribution: Shows the count of of client devices per OS build such as 1803,1809, 202H2 etc.
• Co-management status: A pie chart shows the number of devices with enrollment states.
• Co-management enrollment status: A pie chart shows the number of devices with the enrollment status especially on the device join status.
• Enrollment errors: (Top 5) A table shows the count of devices that has enrollment errors.
• Workload transition: A bar chart with the number of devices that are transitioned to Microsoft Intune.
• And finally, a List of all devices from the collection that you have selected, with its co-management status, enrollment status, client inventory data along with managed workloads of specific device.

To use this report, you have 2 options :

• Subscribe to our membership, download the RDL file, upload it to your SCCM server Report server and run the report. The membership also allows to have future versions and many other perks
• If you’re not interested in our subscription, the report can be bought as a single product.

We hope that this is helpful in your transition from SCCM to Intune.
